Description
Peak Loupe 30x has been enjoying favorable reception from customers as a loupe of high magnification by the design of 4 elements, 2 groups, allowing erect image vision. This excellent magnifier fitted with a glass scale (scale divisions = 0.05mm) to meet the demands from the many different sectors. Thereby making it possible to measure and compare the object to be inspected over the entire effective visual field of 7mm.
| Item Number | 2037 | 2037-L |
| Magnification | 30x | 30x |
| Effective Aperture | 7 mm | 7 mm |
| Size (mm) | 30øx19 | 43øx65x184 |
| Net Weight | 16 g | 48 g |
| Scale Length | 5 mm | 5 mm |
| Min. Scale Division | 0.05mm | 0.05mm |
