CCTV Monitor Specification Comparison Chart

B/W Series




 Specifications \ Model No. MM-9M
Side-by-side Rack Type
MM-9A MM-12A MM-15
MM-15A
MM-20
MM-20A
 Picture Tube 10" CRT (MM-9)
14" CRT (MP-14)
90 B/W P4
10" CRT

90 B/W P4
12" CRT

90 B/W P4
15" FST

90 B/W P4
20" CRT

114 B/W P4
 Horizontal Resolution >800 TVL (MP-14>1000TVL) >1000 TVL
 Video Input / Output BNC x 1 set BNC x 1 set BNC x 1 set BNC x 1 set BNC x 1 set
 Audio Input / Output None Yes Yes None (MM-15)

Yes (MM-15A)
None (MM-20)

Yes (MM-20A)
 Video Standard (EIA/CCIR) EIA or CCIR
 Power Consumption (max.) 20W (MM-9)

22W (MP-14)

20W 30W 35W 35W
 Cabinet Plastic Metal
 Power Supply Universal AC 100~240 V
 Dimension (WxHxD mm) 236x233x246 (MM-9)
324x287x325 (MP-14)
222 x 243 x 250 304 x 320 x 310 350 x 350 x 360 472 x 450 x 360


Color Series


 Specifications \ Model No. CM-14DNA
CM-14VNA
CM-10DXA CH-15DXA CH-17DXA CH-19DXA CM-21DXA
CM-21VXA
 Picture Tube 14" 90

0.63mm

10" 90

0.63mm

15" 90

0.27mm

17" 90 0.25mm

Pure Flat CRT

19" 90

0.27mm

21" 90

0.74mm

 Horizontal Resolution >400 TVL >800 TVL >800 TVL >800 TVL >800 TVL >500 TVL
 Auto Loop Through Yes
 S. VHS Input / Output Y/C x 1 Set
 Video Input / Output BNC x 1 set BNC X 2 sets (DXA Series) / BNC x 1 set (CM-21VXA)
 Audio Input / Output RCA x 1 set RCA x 3 Set / RCA x 1 Set (CM-21VXA)
 Video Standard (NTSC/PAL) Dual
 User's Control Digital (DNA Series)

VR (VNA Series)

Digital OSD (DXA Series)

VR (CM-21VXA)

 Power Consumption (max.) 65W 40W 95W 100W 105W 80W
 Operating Humidity 10% ~ 90% 10% ~ 90% 15% ~ 90% 10% ~ 90%
 Operating Temperature -10C ~ +50C
 Gross Weight 14kgs 8kgs 15kgs 20kgs 25kgs 27kgs
 Cabinet Metal
 Power Supply Universal AC 100~240 V
 Features CH-15DXA, CH-19DXA& CM-9DXA with OU Scan Push-push type on front panel
 Dimension (WxHxD mm) 350x350x360 258x260x302 368x361x376 416x400x417 448x434x448 492x474x482
